2012 Ram 3500 HD Chassis Truck
- Austin Tan Pearlcoat
- Black Clearcoat
- Bright Red
- Bright Silver Metallic Clearcoat
- Bright White Clearcoat
- Case Construction Yellow
- Case IH Red
- Case Power Tan
- D T Green
- Dark Brown
- Deep Cherry Red Crystal Pearlcoat
- Deep Molten Red Pearlcoat
- Detonator Yellow Clearcoat
- Flame Red Clearcoat
- Green Angel
- Inferno Red Crystal Pearlcoat
- Light Cream
- Light Graystone Pearlcoat
- Light Green
- Midnight Blue Pearlcoat
- Mineral Gray Metallic Clearcoat
- National Fire Safety Lime Yellow
- New Holland Blue
- Omaha Orange
- Robin Egg Blue
- Saddle Brown Pearlcoat
- Sagebrush Pearlcoat
- School Bus Yellow
- Sunbelt Yellow
- Tequila Sunrise Pearlcoat
- Timberline Green Pearlcoat
- True Blue Pearlcoat
- Yellow
2012 Ram 3500 HD Chassis Truck Overview
The standard features of the RAM 3500 HD Chassis ST/SLT include HEMI 5.7L V-8 383hp engine, 6-speed automatic transmission with overdrive, 4-wheel anti-lock brakes (ABS), 17" steel wheels, AM/FM stereo in-dash mounted single CD MP3 decoder, with 2 speakers, tilt steering wheel, light tinted windows, 4-way manual adjustment driver & passenger seats, max trailer weight of 11,800lbs., Basic warranty, and a major components warranty.
Specifications
- Tilt steering wheel
- Passenger vanity mirror
- Front beverage holders
- Driver door bin
- Passenger door bin
- Approach angle - 24 deg
- Departure angle - 29 deg
- Ground clearance (min) - 196mm (7.7")
- Ground clearance (max) - 254mm (10.0")
- Ramp breakover angle - 21 deg
- AM/FM radio
- CD player
- MP3 decoder
- Speakers - 2
- Basic warranty - 36 months/36,000miles
- Powertrain warranty - 60 months/100,000miles
- Corrosion perforation warranty - 60 months/100,000miles
- Roadside assistance coverage - 36 months/36,000miles
- Max seating capacity - 3
- Front seats - bench
- Front center armrest - w/storage
- Engine displacement - 5.7 L
- Engine horsepower - 383hp @ 5,600RPM
- Engine torque - 400 lb.-ft. @ 4,000RPM
- Engine bore x stroke - 99.6mm x 90.9mm (3.92" x 3.58")
- Compression ratio - 10.50 to 1
- Payload - 2,945kg (6,493lbs)
- Curb weight - 2,725kg (6,007lbs)
- GVWR - 5,670kg (12,500lbs)
- Towing capacity - 5,352kg (11,800lbs)
- Exterior length - 5,951mm (234.3")
- Exterior body width - 2,004mm (78.9")
- Exterior height - 1,991mm (78.4")
- Wheelbase - 3,645mm (143.5")
- Turning radius - 6.8m (22.5')
- Front legroom - 1,041mm (41.0")
- Front headroom - 1,036mm (40.8")
- Front hiproom - 1,615mm (63.6")
- Front shoulder room - 1,676mm (66.0")
- Passenger volume - 1,812L (64.0 cu.ft.)
- Interior cargo volume - 430 L (15 cu.ft.)
- Interior maximum cargo volume - 430 L (15 cu.ft.)
- Engine liters - 5.7
- Cylinder configuration - V-8
- Horsepower - 383hp @ 5,600RPM
- Torque - 400 lb.-ft. @ 4,000RPM
- Number of valves - 16
- Variable valve control
- Variable intake manifold
- Sequential multi-point fuel injection
- Engine location - front
- Recommended fuel - regular unleaded
- Transmission - 6 speed automatic
- Mode select transmission
- Manual-shift auto
- Drive type - rear-wheel
- Limited slip differential
- Fuel tank capacity - 52.0gal.
- 4 wheel disc brakes
- ABS brakes
- Dual front impact airbags
- Passenger cancellable airbag
- Ignition disable
- Front anti-roll bar
- Rear anti-roll bar
- Power steering
- Front tires - 235/80SR17.0E
- Rear tires - 235/80SR17.0E
- Dual rear wheels
- Wheel size - 17"
- Fully automatic headlights
- Delay-off headlights
- Variably intermittent wipers
- Tachometer
- Voltmeter
Trims
Based on 2008 -2009 EPA mileage estimates, reflecting new EPA fuel economy methods beginning with 2008 models. Use for comparison purposes only. Do not compare to models before 2008. Your actual mileage will vary depending on how you drive and maintain your vehicle.
The prices and incentives shown above may vary from region to region and are subject to change. Inventory is subject to prior sale. Vehicle information is based on standard equipment and may vary from vehicle to vehicle. Please contact us via phone or email for specific vehicle information. All prices plus tax, title, license, dealer adds and documentation fee.
